Precision PEEK Suction Nozzle CNC Milling | Complex Tip Geometry for Pick-and-Place

We successfully delivered a CNC machined PEEK suction nozzle for an automated handling equipment manufacturer. The component features a complex contoured tip for precise pick-and-place operations, while the mounting base remains simple for easy integration. Machined from a solid PEEK billet using 3+2 axis CNC milling, this part ensures high rigidity, chemical resistance, and long-term reliability in cleanroom environments.

Project Overview

Key Technical Highlights

• Complex Tip Contour Milling: Achieved via 3+2 axis CNC milling, ensuring precise geometry for reliable component pickup.
• Simple Base Design: Straightforward mounting interface reduces integration complexity for end-users.
• Single-Setup Machining: Both complex tip and simple base machined in one operation, guaranteeing perfect alignment and reducing lead time.
• PEEK Material Advantages: Lightweight, chemically resistant, and static-free — ideal for semiconductor and medical device handling.

Quality Verification

Full dimensional inspection performed using ZEISS CMM with 1.5μm repeatability. Surface roughness verified on critical tip areas. Material certification provided upon request.

Industry Applications

✓ Semiconductor wafer handling
✓ Medical device assembly
✓ Electronic component pick-and-place
✓ Cleanroom automation systems

Why Partner With Us?

• Expertise in complex 3D contour milling of engineering plastics
• In-house programming and fixture design for optimized machining
• Fast prototyping to production scaling
• Full traceability and material compliance support
